Car Navigation Wifi Bluetooth Face Recognition Camera collision warning system
Customization Features
Driver Face State Recognition
Infrared Camera Available 24 Hours a Day
Driving Video Recording
Through RS232 serial port or 4G/3G/2G mobile networks connection, DB03 can transmit abnormal driver face state event data (photo/video optional) to 3rd party telematics device or cloud server.
DB03 is an independent driver face state recognition device. Based on artificial vision technology, the driver facing camera performs as driver fatigue&distracted monitor system. When the system detects abnormal face state, it will warn the driver by audio.
Performance Specification:
| CPU Frequency | 1.2GHz |
| RAM | 2GB |
| TF Card Slot | Yes |
| SIM Card Slot | Support micro-SIM card |
| Model | DB03 |
| OS | Android |
| ROM | 16GB |
| CPU | Support |
| Micro USB | Yes |
| Network | 4G/3G/2G, Using M2M |
| Driver Facing | Infrared camera |
| Sensors | GPS(Support A-GPS), G-sensor,GYRO |
| Digital Input | 2 |
| Rs232 Serial Port | 1 |
| Operating Voltage | 10V- 32V DC |
| Loudspeaker & Microphone | Bulit-in |
| Video Output | RCA (male) ,CVBS |
| Operating Temperature | -20 ~+85 |
Product Function:
Driver Smoking Warning
Setting: above 0.5 second.
Driver on the Phone Warning
Setting: above 5 seconds after keeping the gesture of calling.
No Driver Face Detected Warning
Setting: above 20 seconds.
Data Transmission via RS232 Serial Port
Send event data (photo optional) to 3rd party telematics devices like GPS vehicle tracker, MDVR, OBD dongle, etc.
Driving Video Recording
Record every moment while driving and save the videos inside the TF card. Users can remove the TF card to obtain the videos or use Roadeye App to download the videos from TF card to Android smartphone via DB03’s WiFi hotspot.
Driver Eye Close Warning
Setting: above 1 second as level 1 and 2 seconds as level 2.
Driver Yawning Warning
Setting: above 0.8 second.
Driver Distracted (Inattention) Warning
Setting: above 4 seconds.
